Description:
The SR8363 series are a group of low-dropout ( LDO ) voltage regulators offering the benefits of wide input voltage range, low dropout voltage, low power consumption, and miniaturized packaging. Quiescent current of only 2.2μA makes these devices ideal for powering the battery-powered, always-on systems that require very little idle-state power dissipation to a longer service life. There is an option of shutdown mode by selecting the parts with the EN pin and pulling it low. The shutdown current in this mode goes down to only 10nA ( typical ). The SR8363 series of linear regulators are stable with the ceramic output capacitor over its wide input range from 2V to 36V and the entire range of output load current ( 0mA to 200mA ).
Features:
_2.2μA Ground Current at no Load
_±2% Output Accuracy
_200mA Output Current
_10nA Disable Current
_Wide Operating Input Voltage Range: 2V to 36V
_Dropout Voltage: 0.66V at 100mA / VOUT 5V
_Support Fixed Output Voltage 1.8V, 3.3V, 5V, 9V, 12V
_Stable with Ceramic or Tantalum Capacitor
_Current Limit Protection
_Over-Temperature Protection
_SOT-23-5 Package
Applications:
_Portable, Battery Powered Equipment
_Low Power Microcontrollers
_Laptop, Palmtops and PDAs
_Wireless Communication Equipment
_Audio/Video Equipment
_Car Navigation Systems
_Industrial Controls
_Weighting Scales
_Meters
_Home Automation
