Description:
PD fast charging protocol chip SR7603PD6 is a 6-pin PD fast charging protocol chip in SOT23-6 package. It is a compact peripheral, low cost, high performance, 18W/20W/25W PD mature protocol scheme. Its application circuit is simple, high cost performance. At the same time will provide 18W/20W/25W power, maximum 12V voltage, commonly used in 20W PD quick charging electrical protocol chip.
PD fast charge protocol chip SR7603PD6 This compact (18W/20W/25W) can replace SW7601 / JSTU6602 / V6006C / DK601 and other PD fast charge protocol chips.
Features:
_On-chip Multiple Charging Standard Identification:
———————————————————————————————————
_USB Power Delivery 3.0 Fix PDO (support 18W/20W/25W configurations)
_USB Power Delivery 2.0 Fix PDO
_USB Type C CC-logic
———————————————————————————————————
_4kV HBM and 200V MM Contact ESD Level
_Operating Temperature: -40OC ~ 125OC
_Package: SOT23-6
Applications:
_Wall Adapter
_Car Charger
_Portable Power Bank
_USB Power Plugs
